Yamaha RDX-E700 rádio-zosilňovač-CD/DVD prehrávač MP3

51
English
ADDITIONAL
INFORMATION
AMPLIFIER SECTION
• Minimum RMS output power per channel (20 kHz Factory LPF)
(6 Ω , 1 kHz, 0.18% THD) ....................................... 20 W + 20 W
• Maximum RMS output power per channel (20 kHz Factory LPF)
(6 Ω , 1 kHz, 10% THD) .......................................... 30 W + 30 W
• Total Harmonic Distortion
AUX etc (1 Channel Driven, 1 kHz)..................... less than 0.08%
• Input sensitivity/Impedance
AUX etc .................................................................. 300 mV/47 kΩ
• Frequency Response
AUX etc ...................................................... 10 Hz to 22 kHz ±3dB
• Signal to Noise ratio
(20 kHz Factory LPF, IHF-A network, Shorted)
AUX etc (0 dB Input) ............................................................ 93 dB
VIDEO SECTION
• Video Signal Level
Video........................................................................... 1 Vp-p/75 Ω
Component............................................................1 Vp-p/75 Ω (Y)
0.7 Vp-p/75 Ω (PB , P R)
Signal to Noise ratio .............................................................. 72 dB
TUNER SECTION
FM Section
• Tuning Range................................................... 87.50 to 108.00 MHz
• Signal to Noise ratio (Mono) .................................................... 75 dB
• Sensitivity (S/N 30 dB)........................................................... 1.0 μV
AM Section
• Tuning Range
U.S.A. and Canada models ...................................530 to 1700 kHz
Other models.........................................................522 to 1629 kHz
• Signal to Noise ratio ................................................................. 32 dΒ
• Sensitivity (S/N 20 dB).......................................................... 700 μV
CD/DVD PLAYER SECTION
• Signal to Noise ratio ................................................................. 95 dB
• Total Harmonic Distortion ..................................................... 0.007%
• Separation ................................................................................. 90 dB
AUDIO FORMAT
• Dolby Digital/MPEG decode (not decode DTS)
• PCM DATA: 16 bit
• LPCM DATA: 20/24 bit
Fs: 44.1, 48 kHz support/88.2, 96 kHz downmix support
• MP3: 32 kbps to 320 kbps, 16 kHz to 48 kHz sampling rate
• WMA: Up to 192 kbps (not support 32 kbps),
32 kHz, 44.1 kHz, 48 kHz sampling rate
• Support mono and stereo WMA/MP3 and VBR files
GENERAL
• Power Supply
U.S.A. and Canada models ..................................AC 120 V, 60 Hz
Australia model ....................................................AC 240 V, 50 Hz
U.K. and Europe models ......................................AC 230 V, 50 Hz
Korea model .........................................................AC 220 V, 60 Hz
Asia model ............................
